DOTS PER INCH (DPI) RGBWW Configurable LED RGB 2700K-5000K Light Sheet

Professional flexible light sheet creates uniform and linear illumination. Easy installation in any minimal size application with no heat sink needed.

May be field-cut vertically or horizontally, in unique shapes or around obstructions
Powers easily by daisy chaining with integral gold plate connectors or power from any square at soldering points provided
Can be installed in either exposed or fully enclosed spaces
One 2" joiner cable is included per sheet
Color Tunable through matching DMX LED controller A2C10-3

thumbnail-image

thumbnail-image

thumbnail-image

thumbnail-image

Specifications

Order Number: A2S-05-CCWT

model
A2S-05-CCWT - DOTS PER INCH RGBWW 12x24 Configurable LED Light Sheet A2S-10-CCWT - DOTS PER INCH RGBWW 12x24 Configurable LED Light Sheet

Components

DMX LED CONTROLLER 3X96W 24VDC

REMOTE POWER SUPPLY 24VDC 96W

REMOTE POWER SUPPLY 24VDC 96W

DMX LED CONTROLLER 10X96W 24VDC

DIN RAIL POWER SUPPLY 24VDC 480W

Accessories

JOINER CABLE

I CONNECTOR

JOINER CABLE EXTENDER

5-3 TERMINAL LOW VOLTAGE WIRING BOX

T CONNECTOR

X CONNECTOR

L CONNECTOR

FLEXIBLE TAPE-TO-TAPE Y CONNECTOR

FLEXIBLE TAPE-TO-TAPE X CONNECTOR

IN WALL RATED JOINER CABLE

IN WALL RATED EXTENSION CABLE

DOTS PER INCH (DPI) STANDOFF

LINE DRAWING

FEATURES
CERTIFICATIONS
CCT

May be field-cut vertically or horizontally, in unique shapes or around obstructions
Powers easily by daisy chaining with integral gold plate connectors or power from any square at soldering points provided
Can be installed in either exposed or fully enclosed spaces
One 2" joiner cable is included per sheet
Color Tunable through matching DMX LED controller A2C10-3

yes

ul, cul

damp

cct-image
